Fuel Moto E-Series Dyna 2-into-1 Full System

Product Information

Price Range: $799.00 - $995.00

Description

The E-Series 2/1 full system is designed to make superior horsepower and torque at an especially reasonable dB level. These systems have been tested extensively on the dynamometer as well as in real world conditions for optimum performance. Each 2/1 full system features a baffle system which provides maximum flow and attenuation of sound waves to create an awesome deep, low frequency exhaust note which is further accentuated by our evolutionary tuneable elliptical diffuser disc system.

  • Featuring a 304 stainless steel hi-output header which is hand built & fully TIG welded.
  • Tapered & stepped primaries. Tested and developed on motors from stock to over 150+ horsepower!
  • Includes both 12mm & 18mm bungs. This allows for both stock & wide band oxygen sensors to be used.
  • E-Series tuneable muffler with 15 E-Series discs included.
  • Available in show chrome finish.
  • 2.5" full length heat shields for superior coverage.
  • Fits all 2006-Current H-D Dyna models (excluding FLD Switchback).
  • Made in the U.S.A.

Every single Fuel Moto E-Series exhaust system model is put through and extensive R&D process that includes power, sound, air/fuel curves, mapping, fitment and finish. No detail is left undone. If you have any questions, please contact us at 920-423-3309.

Dyno Charts

2013 HD Dyna 103ci

To the right is a dyno chart from a completely stock 2013 HD Dyna 103" compared to the addition of the E-Series 2/1 Exhaust and a Stage 1 air cleaner - all tuned with the Dynojet Power Vision.

2014 HD Dyna 103ci

To the right is a dyno chart from a 2014 HD Dyna 103" with the addition of the E-Series 2/1 Exhaust, Wood Performance TW-555 cams and a Stage 1 air cleaner - all tuned with the Dynojet Power Vision.

2013 HD Dyna 103ci

To the right is a dyno chart from a 2013 HD Dyna with the addition of the E-Series 2/1 Exhaust Fuel Moto 117" big bore kit at 12.6:1 compression, Gary Williams raised port heads, Woo Performance TW-68G cams and a Horse Power Inc 62mm throttle body - all tuned with the Dynojet Power Vision.
