Harley Trouble Codes

Harley Trouble Codes DISCLAIMER: this information is for reference only. Fuel Moto does not offer technical support for diagnostic trouble codes. The following procedure will instruct in retrieving and clearing ECM Diagnostic Trouble Codes and TSM/TSSM codes through the Harley gauge cluster as well as a list of codes.

1- Turn Ignition switch to OFF & Run/Stop switch is to Run.

2- Push odometer reset button in & hold. For 2014 & newer touring models this will be the toggle switch on the left control mount.

3- Turn ignition switch to Ignition and release the odometer reset button. Background lighting should illuminate, speedometer needle should sweep its full range and indicator lamps (battery, security, low fuel, check engine and cruise) should illuminate. The word "diag" should then appear.

4 - Push the odometer reset button once and you will see the selection menu "PSSPt" with the first P flashing.

5 - Each letter represents an area of the diagnostics module. The module that is flashing is the one you are going to check. To move from one letter (module) to the next, you push the odometer reset button one time. (from P to S to SP to t and back to P, etc.)
P = ECM/ICM(Electronic Control Module)[EFI] /Ignition Control Module[Carbureted])
S = TSM/TSSM (Turn Signal/ Security Module)
SP = speedometer
T = tachometer

6 - To get the DTC within an area of diagnostics, push and hold the odometer reset button in for 5 seconds and release. If there are any DTC's the code will be displayed or the word "none" will appear if there are no DTC's. Push the odometer reset button again to view additional codes if they exist.

7 - Record the codes.

8 - If DTC's are not to be cleared, Press and release the odometer reset button. Part number of module will be displayed.
NOTE: To determine if a code is current or historic, clear the displayed code by pushing in and holding the odometer reset button ( longer than 5 seconds) until 'clear' comes up. Release the odometer reset button. Turn OFF the ignition switch. Run your bike and shut it down then recheck the DTC's again by repeating steps 1 to 9. If the code is current it will reappear.

9 - Press and release the odometer reset button to continue to the next module.

10 - Turn Ignition switch to OFF.

On models not equipped with a tachometer "No Rsp" will appear when the tachometer identifier is selected.

"No Rsp" (no response) will also appear if the run/off switch is in the off position when doing this procedure.

--------------------------

HFSM = Hands Free Security Module
TSM = Turn signalmodule

DTC’s are designated by a P,C,B or U
P codes indicate issues monitored by ECM
C codes indicate an issue with ABS
B codes are set by Radio, Instruments and BCM
U codes indicate a communication problems with the modules

Fault Code Abbreviation List

ABS – Anti-Lock Braking System
ACR – Automatic Compression Release
AFR – Air Fuel Ratio
AIS – Active Intake Solenoid
ATS – Air Temperature Sensor
BAS – Bank Angle Sensor
BCM – Body Control Module
CAN – Controller Area Network
CCM – Cruise Control Module
CKP – Crank Position Sensor
DLC – Datalink Connector
DTC – Diagnostic Trouble Codes
ECM – Electronic Control Module
ECT – Engine Coolant Temperature
ECU – Electronic Control Unit
EFI – Electronic Fuel Injection
EFP – Electronic Fuel Pump
ET – Engine Temperature sensor
FI – Fuel Injectors
FPR – Fuel Pressure regulator
H-DSSS – Harley-Davidson Smart Security System
HCU – Hydraulic Control Unit, ABS
HFSM – Hands Free Security Module
HO2S – Heated Oxygen Sensor
IAC – Idle Air Control actuator
IAT – Intake Air Temperature sensor
ICM – Ignition Control Module
IMAP – MAP + IAT in one unit
ISS – Ion Sensing System
JSS – Jiffy Stand Sensor
LHCM – Left Hand Control Module
MAP – Manifold Absolute Pressure Sensor
MHR – Right Hand Control Module
RCM – Reverse Control Module
TCA – Throttle Control Actuator
TGS – Twist Grip Sensor
TMAP – Intake Air Temperature / Manifold Absolute Pressure equipment
TPS – Throttle Position Sensor
TSM / TSSM – (Turn Signal / Turn Signal Security Module)
VE – Volume Efficiency
VIN – Vehicle identification number
VSS – Vehicle Speed Sensor
WSS – Wheel Speed Sensor

  • P0031 Front HO2S low/open
    P0032 Front HO2S shorted/high
    P0051 Rear HO2S low/open
    P0052 Rear HO2S shorted/high
    P0072 AAT sensor low
    P0073 AAT sensor high/open
    P0107 MAP sensor failed low/open
    P0107 Map Sensor Open/Low
    P0108 MAP sensor failed high/open port
    P0112 IAT Voltage Low
    P0113 IAT Voltage Open/High
    P0117 ET Sensor Low
    P0118 ET Sensor High
    P0120 TPS1 Range Error
    P0122 TPS1 Low
    P0123 TPS2 High/Open
    P0131 Front Oxygen Sensor Low / Engine Lean
    P0132 Front Oxygen Sensor High / Engine Rich
    P0134 Front Oxygen Sensor Inactive
    P0151 Rear Oxygen Sensor Low / Engine Lean
    P0152 Rear Oxygen Sensor High / Engine Rich
    P0154 Rear Oxygen Sensor Inactive
    P0220 TPS2 Range Error
    P0222 TPS2 Low/Open
    P0223 TPS2 High/Open
    P0261 Front Injector Open/Low
    P0262 Front Injector High
    P0263 Rear Injector Open/Low
    P0264 Rear Injector High
    P0265 Rear injector shorted high
    P0371 CKP sensor wrong number of pulses
    P0373 CKP Sensor Intermittent
    P0374 CKP Sensor Synch Error
    P0444 Purge Solenoid Open/Low
    P0445 Purge Solenoid High
    P0501 VSS Sensor Low
    P0502 VSS Sensor High/Open
    P0503 VSS failed high
    P0505 Idle speed control unstable
    P0562 Battery/ECM Voltage Low
    P0563 Battery/ECM Voltage High
    P0572 Brake Switch Low
    P0577 Cruise Control Input High
    P0603 ECM EEPROM Memory Error
    P0605 ECM FLASH Memory Error
    P0641 5 Volt Reference 1 Out of Range
    P0651 5 Volt Reference 2 Out of Range
    P0691 Fan/cooling relay output low/open
    P0692 Fan/cooling relay output high
    P1001 System Relay Coil Open/Low
    P1002 System Relay Coil High/Shorted
    P1003 System relay contacts open
    P1004 System Relay Contacts Closed
    P1009 VTD Disabled Fuel Due to Incorrect Password
    P1010 Missing Password
    P1017 ET indicates overheating
    P1019 ECT Difference (high temp)
    P1270 TGS 2 A/D Validation Error
    P1351 Front Ignition Coil Driver Open/Low
    P1352 Front Ignition Coil Driver High/Shorted
    P1353 Front Cylnder No Combustion
    P1354 Rear Ignition Coil Driver Open/Low
    P1355 Rear Ignition Coil Driver High/Shorted
    P1356 Rear Cylinder No Combustion
    P1357 Front Cylinder Combustion Intermittent
    P1358 Rear Cylinder Combustion Intermittent
    P1475 Exhaust Actuation Position Error
    P1477 Exhaust Actuator Open/Low
    P1478 Exhaust Actuator Shorted/High
    P1501 Jiffy Stand Sensor Low
    P1502 Jiffy Stand Sensor High
    P1510 EFI Limited Performance Mode
    P1511 EFI Power Management Mode
    P1512 EFI Forced Idle Mode
    P1514 ETC Air Flow Fault/Error
    P1600 EFI Module Processor Internal Error / Watchdog Error
    P1608 Loss of continuous battery
    P1655 ACR solenoid low/open
    P1656 ACR solenoid shorted high
    P1691 Cooling fan left low/open
    P1692 Cooling fan left shorted high
    P1693 Cooling fan right low/open
    P1694 Cooling fan right shorted high
    P2100 EFI Motor Circuit Open
    P2101 EFI Motor Circuit Range Performance (Actuation Error)
    P2102 EFI Motor Circuit Low
    P2103 EFI Motor Circuit High
    P2105 EFI Forced engine shutdown
    P2107 EFI Module Processor Internal Fault
    P2119 EFI Motor Throttle Body RangePerformance
    P2122 TGS1 Low/Open
    P2123 TGS1 High
    P2127 TGS2 Low/Open
    P2128 TGS2 High
    P2135 TPS Correlation Error
    P2138 TGS Correlation Error (Twist grip sensor)
    P2176 EFI Closed Position Not Learned
    P2184 ECT sensor low
    P2185 ECT sensor high
    P2300 Ignition coil driver low/open (front)
    P2301 Ignition coil driver shorted high (front)
    P2303 Ignition coil driver low/open (rear)
    P2304 Ignition coil driver shorted high (rear)

  • C0562 ABS voltage low
    C0563 ABS voltage high
    C1014 ABS ECU relay error
    C1021 ABS front WSS always zero
    C1023 ABS rear WSS always zero
    C1025 ABS Front wheel speed intermittent
    C1027 ABS rear wheel speed intermittent
    C1029 ABS wheel speed difference too high
    C1032 ABS Front wheel speed circuit open/shorted
    C1034 ABS rear wheel speed circuit open/shorted
    C1040 ABS pump/motor error
    C1055 ABS ECU internal error
    C1061 ABS front apply solenoid circuit open/high resistance
    C1062 ABS front release solenoid circuit open/high resistance
    C1065 ABS rear apply solenoid circuit open/high resistance
    C1066 ABS rear release solenoid circuit open/high resistance
    C1071 Rear prime valve error
    C1072 Rear isolation valve error
    C1073 Front isolation valve error
    C1074 Front prime valve error
    C1075 Front linked inlet valve error
    C1076 Front linked outlet valve error
    C1077 Front circuit pressure sensor error
    C1078 Rear circuit pressure sensor error
    C1081 Front master pressure sensor error
    C1082 Front master pressure sensor offset error
    C1083 Front wheel pressure sensor error
    C1084 Front wheel pressure sensor offset error
    C1085 Rear master pressure sensor error
    C1086 Rear master pressure offset sensor error
    C1087 Rear wheel pressure sensor error
    C1088 Rear wheel pressure sensor offset error
    C1089 Pressure sensor external supply error
    C1159 ABS invalid stored VIN
    C1178 ABS no VIN received from ECM
    C1184 ABS invalid VIN from ECM
    C1195 Wake up error

  • B0563 Battery Voltage High
    B1103 LHCM Internal error
    B1121(HFSM) Left Turn Output Open
    B1121(TSM) Left Turn Output Fault
    B1122(HFSM) Right Turn Output Open
    B1122(TSM) Right Turn Output Fault
    B1123(HFSM) Left Turn Output Short to Ground
    B1124(HFSM) Right Turn Output Short to Ground
    B1125(HFSM) Left Turn Output Short to Battery
    B1126(HFSM) Right Turn Output Short to Battery
    B1131(HFSM) Alarm Output Low
    B1132(HFSM) Alarm Output High
    B1134 Starter Output High
    B1135 Accelerometer Failed
    B1136(HFSM) Accelerometer Tip Test Error
    B1141(HFSM) Ignition SwitchLow/Open
    B1141(TSM) Ignition SwitchLow/Open
    B1142 Smart Security System Internal Fault
    B1143(HFSM) Security Antenna Short to Ground
    B1144(HFSM) Security Antenna Short to Battery
    B1145(HFSM) Security Antenna Open
    B1151 Bank Angle Sensor(BAS) Short to Ground
    B1152 Bank Angle Sensor(BAS) Short to Battery
    B1153 Bank Angle Sensor(BAS) High
    B1153 RHCM internal error
    B1154 Clutch Switch Input Short to Ground
    B1155 Neutral Switch Input Short to Battery
    B1200 IM internal fault
    B1210 Fuel level sender shorted low/open
    B1211 Fuel level sender shorted high
    B1212 Fuel signal low
    B1213 Fuel signal high
    B1300 Radio voltage high
    B1301 Radio voltage low
    B1302 Face plate home button stuck
    B1303 Face plate favorite button stuck
    B1304 Face plate navigation button stuck
    B1305 Face plate power/mute button stuck
    B1306 Rear hand controls shorted high
    B1307 Rear hand controls shorted low
    B1308 Rear volume up button stuck
    B1309 Rear volume down button stuck
    B1310 Rear mode button stuck
    B1311 Rear PTT button stuck
    B1312 Rear tune up button stuck
    B1313 Rear tune down button stuck
    B1314 LHCM VR button stuck
    B1315 LHCM up button stuck
    B1316 LHCM left button stuck
    B1317 LHCM center button stuck
    B1318 LHCM right button stuck
    B1319 LHCM down button stuck
    B1320 RHCM Info button stuck
    B1321 RHCM up button stuck
    B1322 RHCM left button stuck
    B1323 RHCM center button stuck
    B1324 RHCM right button stuck
    B1325 RHCM down button stuck
    B1326 RHCM CB squelch up button stuck
    B1327 RHCM CB PTT button stuck
    B1328 RHCM CB squelch down button stuck
    B1329 Faceplate preset button 1 stuck
    B1330 Faceplate preset button 2 stuck
    B1331 Faceplate preset button 3 stuck
    B1332 Faceplate preset button 4 stuck
    B1333 Faceplate preset button 5 stuck
    B1334 Faceplate preset button 6 stuck
    B1335 Faceplate preset button 7 stuck
    B1336 Faceplate preset button 8 stuck
    B1337 Front left speaker shorted together
    B1338 Front left speaker open
    B1339 Front left speaker shorted low
    B1340 Front left speaker shorted high
    B1341 Rear left speaker shorted together
    B1342 Rear left speaker open
    B1343 Rear left speaker shorted low
    B1344 Rear left speaker shorted high
    B1345 Front right speaker shorted together
    B1346 Front right speaker open
    B1347 Front right speaker shorted low
    B1348 Font right speaker shorted high
    B1349 Rear right speaker shorted together
    B1350 Rear right speaker open
    B1351 Rear right speaker shorted low
    B1352 Rear right speaker shorted high
    B1353 Speaker offset DC output
    B1354 GPS antenna open
    B1355 GPS antenna shorted low
    B1356 SDARS antenna open
    B1357 SDARS antenna shorted
    B1358 Front left headset shorted high
    B1359 Front right headset shorted high
    B1360 Front left headset shorted low
    B1361 Front right headset shorted low
    B1362 Rear left headset shorted high
    B1363 Rear right headset shorted high
    B1364 Rear left headset shorted low
    B1365 Rear right headset shorted low
    B1366 Internal thermal shutdown error
    B1401 Amp voltage low
    B1402 Amp voltage high
    * Amp 1 Amp 2
    B1403 Speaker offset DC output *
    B1404 Internal thermal shutdown error *
    B1405 EQ correlation error
    B1406 Invalid or missing EQ
    B1410 Channel 1 speaker open *
    B1411 Channel 1 speaker shorted low *
    B1412 Channel 1 speaker shorted high *
    B1413 Channel 1 Speaker shorted together *
    B1420 Channel 2 speaker open *
    B1421 Channel 2 speaker shorted low *
    B1422 Channel 2 speaker shorted high *
    B1423 Channel 2 speaker shorted together *
    B1430 Channel 3 speaker open *
    B1431 Channel 3 speaker shorted low *
    B1432 Channel 3 speaker shorted high *
    B1433 Channel 3 speaker shorted together *
    B1440 Channel 4 speaker open *
    B1441 Channel 4 speaker shorted low *
    B1442 Channel 4 speaker shorted high *
    B1443 Channel 4 speaker shorted together *
    B2102 System power output shorted high
    B2103 System power output shorted low
    B2104 System power output overloaded
    B2106 L4 output open
    B2107 L4 output shorted high
    B2108 L4 output shorted low
    B2109 L4 output overloaded
    B2112 ACC output shorted high
    B2113 ACC output shorted low
    B2114 ACC output overloaded
    B2116 Fuel pump output open
    B2117 Fuel pump output shorted high
    B2118 Fuel pump output shorted low
    B2119 Fuel pump output overloaded
    B2121 Starter output open
    B2122 Starter output shorted high
    B2123 Starter output shorted low
    B2124 Starter output overloaded
    B2127 E4 output shorted high
    B2128 E4 output shorted low
    B2129 E4 output overloaded
    B2131 High beam output open
    B2132 High beam output shorted high
    B2133 High beam output shorted low
    B2134 High beam output overloaded
    B2136 Low beam output open
    B2137 Low beam output shorted high
    B2138 Low beam output shorted low
    B2139 Low beam output overloaded
    B2141 Left front turn signal output open
    B2143 Left front turn signal output shorted low
    B2144 Left front turn signal output overloaded
    B2146 Right front turn signal output open
    B2148 Right front turn signal output shorted low
    B2149 Right front turn signal output overloaded
    B2151 Left rear turn signal output open
    B2153 Left rear turn signal output shorted low
    B2154 Left rear turn signal output overloaded
    B2156 Right rear turn signal output open
    B2158 Right rear turn signal output shorted low
    B2159 Right rear turn signal output overloaded
    B2161 Brake lamp output open
    B2163 Brake lamp output shorted low
    B2164 Brake lamp output overloaded
    B2168 Running lights output shorted low
    B2169 Running lights output overloaded
    B2172 H2 output shorted high
    B2173 H2 output shorted low
    B2176 Security antenna output open
    B2177 Security antenna output shorted high
    B2178 Security antenna output shorted low
    B2183 G2 output shorted low
    B2188 G3 output shorted low
    B2193 H4 output shorted low
    B2198 H3 output shorted low
    B2201 IGN switch off w/VSS
    B2203 Ignition switch input shorted low
    B2206 Run/stop switch input open/shorted high
    B2208 Run/stop switch input shorted low
    B2210 Run/stop switch inputs both open
    B2212 Run/stop switch inputs both closed
    B2218 Neutral switch shorted low
    B2223 Rear brake switch shorted low (light on)
    B2226 BAS input open
    B2228 BAS input shorted low
    B2231 Fork locked/VSS
    B2232 Fork lock shorted high
    B2233 Fork lock shorted low
    B2234 Fork lock detected with option disabled
    B2235 Fork lock configuration invalid
    B2250 Clutch switch stuck
    B2251 Horn switch stuck
    B2253 FTP switch stuck
    B2254 Left turn switch stuck
    B2255 Trip switch stuck
    B2256 LHCM Police siren power stuck
    B2257 LHCM Police siren wail power stuck
    B2258 LHCM police siren yelp stuck
    B2260 Start switch stuck
    B2261 Right turn switch stuck
    B2262 Front brake switch stuck
    B2263 Hazard switch stuck
    B2264 RHCM police lights power switch stuck
    B2265 RHCM police lights front switch stuck
    B2266 RHCM police lights rear switch stuck
    B2267 RHCM police ICR switch stuck
    B2270 BCM internal error
    B2271 BCM voltage low
    B2272 BCM/IM voltage high
    B2274 Constant battery line error

  • U0001 CAN BUS error
    U0002 CAN comm bus perf error
    U0003 Network management monitoring
    U0100 Lost comm w/ECM
    U0121 Lost comm W/ABS
    U0140 Lost comm W/BCM
    U0141 Lost comm w/LHCM
    U0142 Lost comm w/RHCM
    U0156 Lost comm w/SPEEDO
    U0158 Lost comm w/fuel gauge
    U0159 Lost comm w/volt gauge
    U0160 Lost comm w/ fuel and volt gauge
    U0184 Lost comm w/radio
    U0185 Lost comm w/Amp 1
    U0186 Lost comm w/ AMP 2
    U1016 Loss of ECM Serial Data
    U1064 Loss of TSM/FSFM Serial Data to ECM
    U1097 Loss of SpeedometerSerial Data to ECM
    U1255 Serial Data Error
    U1300 ECM Serial Data Low
    U1300 Serial Data Low
    U1301 ECM Serial Data High
    U1301 Serial Data High
    U1302 ACC bus perf error
    U1401 Lost com w/CB
